• 1" x 8" Copper Clad Steel Wire stranded 16mm2  to 300mm2
1" x 8" Copper Clad Steel Wire stranded 16mm2  to 300mm2

1" x 8" Copper Clad Steel Wire stranded 16mm2 to 300mm2

Product Details:

Place of Origin: CHINA
Brand Name: QDCD
Certification: ISO
Model Number: CCSRW

Payment & Shipping Terms:

Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: By wooden case or pallet
Delivery Time: 20-25days
Payment Terms: T/T
Supply Ability: 3000-6000M/day
Get Best Price Contact Now

Detail Information

Tensile Strength: 1350-1650Mpa Surface Treatment: Annealed
Copper Layer Hardness: HV30-80 Copper Layer Elongation: ≥15%
Copper Layer Corrosion Resistance: ≥Grade1 Diameter: 14.2mm/15.8mm
Copper Layer Torsion Strength: ≥90N/mm2 Material: Cold Draw High Quality Mild Steel
High Light:

1" x 8" Copper Clad Steel Wire

,

Copper Clad Steel Wire 16mm2

,

stranded Copper Steel Wire

Product Description

90N/mm2 Annealed Copper Clad Steel Wire with Elongation ≥15%

Product Description:

The surface of steel core is usually covered in copper uniformly. Depending on the production method, there are two types of copper-clad steel: continuous casting copper-clad steel and electroplating copper-clad steel.

Continuous casting copper-clad steel is required to have a high concentration of copper and a small amount of oxygen. It is usually made by making the molten steel enter a copper mould while spinning at a high speed.

Electroplating copper-clad steel is metal materials which are made by immersing the steel core with lower copper concentration into the plating tank and depositing copper on the surface of the steel core under the action of electric current.



Features:

The copper layer is uniform in thickness, ensuring high tensile strength. Besides, it has superior corrosion-resistant capability, proven with more than 30 years of flawless operations in the most rigorous soil conditions.

Moreover, its design and use of exothermic welding technology enable quicker and more successful field construction, leading to greatly improved work efficiency and a much shorter construction period.



Applications:

QDCD's Copper Clad Steel Wire (CCSRW) is a reliable product for a wide range of applications, offering an effective solution to many needs. This steel wire covered in copper is composed of a copper layer that is tightly bonded to a steel core, making the wire both durable and malleable. It is ISO certified and comes in 14.2mm/15.8mm diameter with copper layer torsion strength of ≥90N/mm2, copper layer hardness of HV30-80, and elongation of ≥15%. It is available in minimum order quantity of Negotiable and with price Negotiable. It is supplied in packages of 500pcs/pallet and Delivery Time of 20-25days, and can be shipped in wooden case or pallet. Payment can be made via T/T. It has a Supply Ability of 3000-6000M/day.



Customization:

We provide customized services for Copper Clad Steel Wire with following properties:

  • Brand Name: QDCD
  • Model Number: CCSRW
  • Place of Origin: CHINA
  • Certification: ISO
  • Minimum Order Quantity: Negotiable
  • Price: Negotiable
  • Packaging Details: By wooden case or pallet
  • Delivery Time: 20-25days
  • Payment Terms: T/T
  • Supply Ability: 3000-6000M/day
  • Copper Layer Adhesion: ≥2.5N/mm
  • Copper Layer Tensile Strength: ≥1350Mpa
  • Copper Layer Hardness: HV30-80
  • Surface Treatment: Annealed
  • Copper Layer Elongation: ≥15%

We specialize in Copper-Plated Steel Wire, Steel Wire with Copper Covering and Steel Cable Clad in Copper.



Packing and Shipping:

Packaging and Shipping for Copper Clad Steel Wire

Copper clad steel wire is primarily packaged in plastic spools and then shipped in waterproof, shock-proof cardboard boxes. The spools are wrapped in a waterproof and shock-proof material to protect the wire. The cardboard boxes are designed to withstand significant wear and tear during shipping.



FAQ:

Q1: What is Copper Clad Steel Wire?

A1: Copper Clad Steel Wire is a conductor material which consists of a steel core and a copper cladding. It is manufactured by drawing steel wire through a copper tube, and then drawing it through a series of dies which reduce the diameter and shape the copper cladding.

Q2: What is the brand name of the Copper Clad Steel Wire?

A2: The brand name of Copper Clad Steel Wire is QDCD.

Q3: What is the model number of the Copper Clad Steel Wire?

A3: The model number of the Copper Clad Steel Wire is CCSRW.

Q4: Where does the Copper Clad Steel Wire come from?

A4: The Copper Clad Steel Wire comes from China.

Q5: Is the Copper Clad Steel Wire certified?

A5: Yes, the Copper Clad Steel Wire is certified by ISO.
